$999.00 USD $1,599.00
Color: Black
Black
White
Free delivery and assembly with velofix available in participating markets*
Learn More
🇺🇸 Available for purchase in US only.
🇨🇦 Based in Canada? Click here** and get $50 off using code: RPP-SHOPVELOFIX-CA


Description: The RadExpand 5 is the fifth generation of Rad’s folding ebikes. We refined our “best folding electric bike” award-winner into the RadExpand, weighing in nearly five pounds lighter and featuring fatter tires, adjustable handlebars for a custom fit, and an included rear rack. Fold-out out to explore, and fold in to store in your vehicle, RV, apartment, or boat: adventures are yours for the taking.

Range: Up to 45 miles

Payload: 275 lb.

Top speed: 20 mph

Motor: 750W Geared Hub, 64 Nm torque

UL status: Tested by ACT compliant to UL-2849 and UL-2271

Battery type: 14Ah External Battery

radexpand, rad mini, mini, rad mini 4, foldable, expand, fold, folding bike, folder, mini fat, travel, storage, boat, rv, folding, folder, fold, step-thru, step through, low step, low-step, the rugged space-saver, rugged space saver

General

GenderUnisex
Best Suited for Riders 4'10" - 5'10" (Approx. bike inseam between 24.5" - 32.25")
Certifications Tested by ACT compliant to UL 2849 and UL 2271
Weight62.5 lb, 54.8 with battery removed
Payload Capacity275 lb
Rear Rack Capacity59 lb

Frameset

FrameAluminum
ForkFixed, Rad custom steel 135 mm hub width, 9 mm quick release

Front Set

HandlebarsAlloy, 27" wide
Tape GripsErgonomic rubber comfort grips

E-Bike Specifications

RangeEstimated 25 - 45 miles per charge
Charger Type48V, 2 Amp Rad Power Bikes smart charger, operates on 100V-240V AC power outlets; No USB port
Battery Type/Weight14Ah 672 Wh external battery, tested by ACT compliant to UL 2271

Drivetrain

Derailleur7-Speed MicroShift RD-M26
Cassette7-speed freewheel, 14-32T
Crankset48T with dual-sided chainring guard, 170 mm crank arms
PedalsComposite platform, CrMo axle with reflectors, standard 9/16" x 20 TPI threading

Brakes

BrakesetBrake system: Mechanical caliper; Brake pads: Semi-Metallic compound; Brake rotors: 180 mm

Saddle & Seatpost

SaddleRad Power Bikes with lifting handle
SeatpostAluminum alloy, 390 mm x 27.2 mm Seatpost Clamp: 31.8 mm diameter

Wheels

Tires/TubesCST BFT 20" x 4.0"
Best Suited for: 4'10" - 5'10" (Approx. bike inseam between 24.5" - 32.25")



Bike inseam sizing chart (Inches)
23 - 24.5" 24.5 - 32.25" 32.25+"
  • You will not be able to ride the bike comfortably.
  • You will be able to pedal and stand over the frame comfortably.
  • Your legs may be too long to get full leg extension when pedaling.

What to Measure

Your “bike inseam” — or inside leg length — is the distance between your body where it sits on your bike saddle and the ground.


It’s typically an inch or two longer than the length of your trousers, but measure to be sure.

You’ll use this number on the chart to get a feel for how the different models will fit you.

How to Measure

Gather the tools needed:

  • Medium-width hardcover book
  • Tape measure
  • A wall you can stand against
  • A trusted friend or relative

Wearing your regular riding shoes and with your back to the wall, stand with your feet spread so there is about 7 inches between them — this is about the distance apart your feet would be when straddling a bike with your feet on the ground (standover height).


Place a hardcover book against the wall with the spine of the book facing upward. Slide the book upwards towards your groin until it is solidly against your body. This may be a bit awkward, but is way more comfortable — and safer! — than trying to ride a bike that is too big.


If you have a buddy helping you, get them to measure from the floor to the top of the book spine while you hold the book in place. If you’re going it alone, carefully hold the book in place and measure from the ground to the top of the book spine.
